Rad Power Bikes Radster Trail

No review yet. Write Review
$2,199.00
$2,299.00
$2,199.00
Shipping calculated at checkout.

Vendor : Rad Power Bikes

Product Type : ebike
SHIPPING AVAILABLE
If you're out of our area, we can ship bikes directly to your front door. Please call us at (713) 816-1390 to check on availability and shipping times!
FREE TEST RIDES
If you are located in the Houston area, we recommend coming for free test rides and a professional bike fitting.
Slider Image

Rugged good looks are just the beginning.

The Radster Trail is an electric off-road bike with the power to do anything, and the range to go anywhere. The 100 Nm motor makes quick work of hills, the 28 mph top speed promises fast-paced fun, and with two frame sizes for a personalized fit, it’s so comfortable that you’ll barely feel like you’re roughing it.

  • Speedometer icon to represent the top speed of this electric bike model

    Top speed28 mph

  • Battery icon with a lightning bolt to represent the max range of this electric bike model

    Range65+ miles

  • Lightning bolt icon to represent the motor power of the electric bike

    Power750W

  • Icon of a weight to represent the payload capacity of the electric bike

    Payload370 lb

  • Logo communicating that this product is UL certified

    SafetyUL Certified

  • Icon of a person riding a bike uphill to communicate torque for this electric bike model

    Torque100 Nm

Electronics

  • Battery

    15Ah 720 Wh Safe Shield Advanced Semi-Integrated Battery, Samsung 50GB or LG M50LT cells, UL Certified to UL-2271

  • Charger

    48VDC, 2 Amp Rad Power Bikes smart charger, operates on 100V-240V AC power outlets

  • Class

    Class switchable 1 to 3. Ships in Class 2 status.

  • Display

    Rad custom color display. See Display section below for details.

  • Hub Motor

    Rear hub 750W, 100 Nm torque
    Stated wattage is the manufacturer’s rated power capacity. Actual power-to-ground wattage is under 750W to ensure ebike regulatory compliance and may vary depending on riding conditions.

  • Lights

    Auto-on feature
    Front: ~200 lumens LED headlight with built-in reflector
    Rear: Integrated taillight with brake light and turn signals

  • Pedal Assist

    Torque sensor, 5 PAS Levels, plus a zero assist option

  • Range

    Estimated 25-65 miles per charge

  • Throttle

    Half twist throttle

  • UL Status

    UL Certified to UL 2849 and UL 2271

  • USB Ports

    One USB-C port, located on remote

To ensure uninterrupted shipping, some parts may differ from those listed. Rest assured, our engineers rigorously test each component to guarantee quality and compatibility.

Components

  • Bell

    Yes

  • Brake System

    Tektro Hydraulic Disc E350

  • Brake Pads

    Tektro semi-metallic P20.11

  • Brake Rotors

    180mm x 1.8mm

  • Crank Set

    50T with dual sided chain ring cover, 170mm crank arms

  • Derailleur

    Shimano 8-speed

  • Fenders

    Front and full rear alloy mudguard

  • Fork

    SR Suntour hydraulic suspension fork, 80mm travel, tapered steerer tube, thru axle

  • Frame

    Aluminum

  • Freewheel/Cassette

    8-speed freewheel 11-34T

  • Lock-on Gearing

    1x8 speed

  • Grips

    Ergonomic rubber comfort grips

  • Handlebar

    Aluminum, 710mm wide

  • Kickstand

    Side mounted, adjustable angle kickstand

  • Pedals

    Alloy Platform, Boron axle with reflectors, standard 9/16" X 20 TPI threading

  • Rear Rack

    Integrated, 55 lb (25 kg) carrying capacity

  • Saddle

    Padded sport saddle with shallow anatomic cut-out and contoured sides

  • Seatpost

    Regular: 350 mm x 31.6 mm
    Large: 400 mm x 31.6 mm

  • Seatpost Clamp

    38.1 mm

  • Shifter

    Shimano 8-speed thumb shifter

  • Stem

    40mm A-head

  • Tires

    Kenda Havok 27.5" X 3.0" with puncture protection and tan sidewall

To ensure uninterrupted shipping, some parts may differ from those listed. Rest assured, our engineers rigorously test each component to guarantee quality and compatibility.

Geometry


Bike graphic with the measurements for a Radster Trail electric off-road bike, size regular
Rider Heights 4'11"-5'8" (150-173 cm)
Bike Weight 77.5 lb (35.2 kg), 68.5 lb (31.1 kg) with battery removed
Payload 370 lb, 290 lb. max rider
Rear Rack Payload 55 lb (25 kg)
Handlebar Height 44.5" (113.0 cm)
Reach 15.2" (386 mm)
Seat Height From ground: 30.5" - 37.5" (78.7 - 95.3 cm)
From pedal bottom stroke: 25" - 33" (64 - 84 cm)
Standover Height 21" (53.3 cm)
Stepover Height 20" (50.8 cm)
Total Length 74" (188 cm)
Wheelbase 46.6" (118.3 cm)
Seat Tube Length 15.0" (380 mm)
